Industrial & Hydraulic Hoses
A comprehensive range of high-performance hoses designed for the toughest industrial applications, from high-pressure hydraulics to chemical transport.
Hydraulic Hoses
| Product Name | Standard | Size ID | W.P (Bar) | Temp (°C) |
|---|---|---|---|---|
| R1AT / 1SN | SAE 100 R1AT / EN 853 1SN | 3/16" - 4" | 10 - 250 | -40 to +100 |
| R2AT / 2SN | SAE 100 R2AT / EN 853 2SN | 3/16" - 4" | 10 - 420 | -40 to +100 |
| 4SP | EN 856 4SP | 1/4" - 2" | 165 - 450 | -40 to +100 |
| 4SH | EN 856 4SH | 3/4" - 2" | 250 - 420 | -40 to +100 |
| R12 | SAE 100 R12 | 3/8" - 2" | 170 - 280 | -40 to +121 |
| R13 | SAE 100 R13 | 3/4" - 2" | 350 | -40 to +121 |
| R15 | SAE 100 R15 | 3/8" - 2" | 420 | -40 to +121 |
PTFE Hoses
Temp Range: -54°C to +260°C
Smooth Bore (R14)
Excellent flow characteristics, easy to clean.
Convoluted
Highly flexible for tight bend radii.
High Pressure Gas
Specialized permeation resistance.
Thermoplastic Hoses
Lightweight and durable hoses for specialized applications including sewer jetting and ultra-high pressure systems.
SAE 100 R7
Medium pressure, non-conductive options available.
SAE 100 R8
High pressure, compact design.
Sewer Jetting
Abrasion resistant cover for harsh environments.
Ultra High Pressure
Proprietary technology for pressures up to 3200 Bar.
Specialty Hoses
Stainless Steel Bellow
Metal flexible hoses for extreme temperatures up to 700°C.
Composite Hoses
Lightweight and flexible for fuel loading/unloading operations.
Large Diameter
Heavy-duty hoses for slurry, mud, and cement transfer.
Hose Guards
Protective PVC spiral guards and textile sleeves to extend hose life and ensure safety.
